330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position
330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position
  • 330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position
  • 330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position
  • 330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position

330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly For Measure Machinery Vibration And Position

Ürün Detayları:
Menşe yeri: Amerika
Marka adı: Bently Nevada
Sertifika: CO.CQ
Model numarası: 330801-28-00-115-03-02
Detay Bilgi
Menşe yeri:
Amerika
Marka adı:
Bently Nevada
Sertifika:
CO.CQ
Model numarası:
330801-28-00-115-03-02
330801:
PROXPAC XL Proximity Dönüştürücü Düzeneği (İngiliz manşon dişleriyle).
-28 (Prob ve Onaylar):
Birden fazla uluslararası tehlikeli alan onayıyla yapılandırılmış 3300 XL 8 mm'lik bir prob içer
-00 (Uzaklık Adaptörü):
Hiçbir ayırıcı bağdaştırıcı takılı değil; mahfaza doğrudan makinenin kasasına oturur.
-115 (Prob Penetrasyon):
Değişken prob manşonu derinliği tam olarak 115 mm'ye ayarlanmıştır.
-03 (Bağlantı Parçaları):
Bir adet 3/4-14 NPT bağlantı parçası, bir adet 3/4-14 NPT ila 1/2-14 NPT paslanmaz çelik redüktör ve
-02 (Montaj Dişi):
Diş boyutu standart 3/4-14 NPT endüstriyel bağlantıdır
Vurgulamak:

High Light

Vurgulamak:

Integrated Cableless Design

,

Built-in Proximitor

,

High-Precision Monitoring

Alım Satım Bilgileri
Min sipariş miktarı:
1
Fiyat:
inquiries
Ambalaj bilgileri:
fabrika mühürlü yeni ve orijinal
Teslim süresi:
2-3 İş günü
Ödeme koşulları:
T/T
Yetenek temini:
Gereklilikler
Ürün Açıklaması
330801-28-00-115-03-02 Bently Nevada PROXPAC XL Proximity Transducer Assembly
For measuring machinery vibration and position in industrial applications.
Product Overview
Unique Selling Point
Integrates the Proximitor sensor and 8mm probe directly inside a rugged PPS explosion-proof housing, completely eliminating external extension cables.
Customer Pain Points Solved
Addresses common field issues like cable damage, signal interference, and moisture ingress, while significantly reducing installation complexity.
Specific Applications
Ideally suited for critical rotating machinery vibration and position monitoring in harsh, hazardous oil, gas, or power plant environments (IP66/Type 4X).
Core Specifications
  • Linear Range: 2.0 mm (80 mils) - Covers a wide movement window to detect both tiny micro-vibrations and massive shaft shifts, preventing catastrophic machine crashes.
  • Target Calibration: AISI 4140 steel - Plug-and-play ready for most standard industrial shafts, completely eliminating the time and cost of field recalibration.
  • Protection Rating: IP66 & Type 4X - High-pressure waterproof and chemical-corrosion proof, ensuring years of maintenance-free operation in open-air rain or harsh oil refineries.
Technical Specifications
Probe Type 3300 XL 8mm eddy current probe
Linear Range 2.0 mm (80 mils)
Sensitivity 200 mV/mil (7.87 V/mm)
Target Material AISI 4140 steel
Frequency Response 0 to 10 kHz
Power Supply -17.5 Vdc to -26 Vdc
Protection Rating IP66 and Type 4X
Housing Material Glass-filled Polyphenylene Sulfide (PPS)
Operating Temperature Housing: -52°C to +100°C; Probe: -52°C to +177°C
Mounting Thread 3/4-14 NPT
Penetration Depth 115 mm
Engineer's Note
"The PROXPAC XL series is a game-changer for field instrumentation. By eliminating the traditional extension cable and housing the Proximitor right at the probe sleeve, it completely removes the #1 failure point in proximity systems--cable damage from moisture and physical pinching. For this specific 330801-28-00-115-03-02 configuration, always verify that your machine casing clearance accommodates the 115 mm penetration depth to ensure the 8mm probe tip sits perfectly within its linear range relative to the shaft."
Frequently Asked Questions
Does the 330801-28-00-115-03-02 configuration require an external extension cable to connect to the rack?
No, it does not. The unique design of the Bently Nevada PROXPAC XL integrates the Proximitor sensor directly inside the protective housing cover. The internal 8mm probe connects straight to this sensor, meaning you only need standard field wiring from the housing terminal block to your 3500 monitoring rack, eliminating external extension cables entirely.
Can this specific transducer assembly be installed on a machine shaft made of a material other than AISI 4140 steel?
Yes, but it will require recalibration or scale factor verification. The assembly comes factory-calibrated for standard AISI 4140 steel to deliver its standard 200 mV/mil sensitivity. If your shaft uses a different alloy (such as K-Monel or Inconel), the output voltage will shift, requiring a custom calibration curve or a Bently Nevada magnetic properties cross-reference sheet.
What is the purpose of the '-00' option, and can I add a standoff adapter later if my insertion depth needs change?
The '-00' option means this unit features a "No Standoff Adapter" design, allowing the housing flange to mount flush against your machine casing. If your plant layout changes and you need to shorten the 115 mm penetration depth, you can order a separate Bently Nevada fluid-loc standoff adapter sleeve to pull the housing back without buying a completely new probe assembly.
